Panasonic Lumix S5 20-60MM Lens Grip Kit
Panasonic Professional AV CamerasPanasonic Lumix S5 Highlights:
PERFECT FOR HYBRID SHOOTING
This hybrid Full-frame mirrorless camera, provides exceptional image quality for photo and video across the sensitivity range within an ergonomic body designed for the quality conscious content creator.
FULL-FRAME 24.2MP CMOS SENSOR WITH DUAL NATIVE ISO TECHNOLOGY
The CMOS Sensor has been optimised to deliver exceptional image quality for both stills and video, while the Dual Native ISO provides a greater level of flexibility when shooting in lower light conditions without the usual increase in visible noise when shooting video.
BEYOND PHOTOGRAPHY
Whether you prefer shooting using the full touch capabilities of the 3.0inch 1.84Mio. dot Free-angle LCD in both recording and playback modes or the OLED Live Viewfinder have confidence in what you are shooting. The Timelapse and Stop-Motion features offer you that a little extra creativity while the improved High Resolution Mode photos can now be saved directly as a JPEG for extremely detailed, 96-megapixel-equivalent images for those moment when resolution is everything.
PROFESSIONAL VIDEO OPTIONS
The needs of the content creator vary from job to job, the LUMIX S5 includes recording modes 4K 60p 4:2:0 10-bit and 4K 30p 4:2:2 10-bit — plus 4K 8-bit with no limitation of video recording time. In the 10-bit setting, 4:2:2 10-bit HDMI output is supported along with simultaneous external drive / SD card recording, means flexibility and creativity are available whenever you head out on a shoot.
DUAL IMAGE STABILISATION
Image Stabilisation is a requirement for content creators on the run. The 5-axis Dual I.S. II system combines In-body and lens stabilisation giving you up to 6.5 stops of benefit on the LUMIX S5, giving you greater confidence that you will get the shot you need.
PRODUCTION TOOL FOR THE CONTENT CREATOR
Creative options at your fingertips, the LUMIX S5 gives you a range of features and functions that will help your ability to tell stories in new and creative ways. V-Log and V-Gamut come preinstalled. With 14+ stops of dynamic range and a wide colour gamut, performance to rival high-end production cameras.
ADVANCED FOCUS TECHNOLOGY
The updated Auto-Focus system in the LUMIX S5 offers all the inherent benefits of a contrast based AF system with improved tracking performance. The updated system features high-speed, high-precision AF, and deep learning technology for recognition of human bodies, heads, faces and eyes as well as animals, for improved reliability.
COMPACT & TOUGH CAMERA BODY
The LUMIX S5 is 30% lighter than the S1 weighing only 714g and smaller than the GH5 without compromising on image quality for either stills or video, featuring a premium design and build quality, with a magnesium alloy frame and splash and dust resistance* construction providing you with peace of mind when shooting in a range of environments.
*Dust and splash resistant does not guarantee that damage will not occur if this camera is subjected to direct contact with dust and water.
SELECT THE RIGHT LENS
The LUMIX S5 camera is using the L-Mount lens mount standard allowing to choose from a wide range of high quality lenses from Panasonic, Leica and Sigma.
- 24.2 Megapixels Full-Frame CMOS Sensor
- Dual native ISO technology
- 5-axis Dual image stabilisation
- Acurate Focusing with Deep Learning Technology
- Live view composite
- High Resolution Mode - 96MP JPEG/RAW images
- Cinema quality V-Log with 14+ stops of dynamic range
- Direct access to quick and slow motion recording
- Free-angle LCD Touch display (1840K-dot)
- OLED live viewfinder (2360K-dot, 0.74x)
- 2x SD Card Slots
- USB battery charge and Power Supply
- WiFi 5GHz/Bluetooth
- Mic and headphone terminal
- L-Mount
- Compatible with the XLR Microphone Adapter (DMW-XLR1)
- Compact and Lightweight
- Dust and Splash resistant*
*Dust and splash resistant does not guarantee that damage will not occur if this camera is subjected to direct contact with dust or water
RECORDING SPECIFICATION | |
Image Sensor Effective Pixels | 24.2 megapixel |
Image Sensor Type | CMOS |
Image Sensor Size | Full fame |
Image Stabilization System | Image sensor shift type (5-axis / 5-stop*), Dual I.S. (Dual I.S. 2 compatible) |
Still Image Recording Format | JPEG (DCF, Exif 2.31), RAW, HLG Photo (CTA-2072) |
Still Image Quality | (3:2) 6000x4000(L) / 4272x2848(M) / 3024x2016(S) / 12000x8000(XL)* / 8496x5664(LL)* *High Resolution Mode. 5184x3456(6K PHOTO) / 3504x2336(4K PHOTO) / 5984x4000(HLG PHOTO, Full-Res.) / 3232x2160(HLG PHOTO, 4K-Res.) (4:3) 5328x4000(L) / 3792x2848(M) / 2688x2016(S) / 10656x8000(XL)* / 7552x5664(LL)* *High Resolution Mode. 4992x3744(6K PHOTO) / 3328x2496(4K PHOTO) / 5312x3984(HLG PHOTO, Full-Res.) / 2880x2160(HLG PHOTO, 4K-Res.) (16:9) 6000x3368(L) / 4272x2400(M) / 3024x1704(S) / 12000x6736(XL)* / 8496x4784(LL)* *High Resolution Mode. 3840x2160(4K PHOTO) / 5888x3312(HLG PHOTO, Full-Res.) / 3840x2160(HLG PHOTO, 4K-Res.) (1:1) 4000x4000(L) / 2848x2848(M) / 2016x2016(S) / 8000x8000(XL)* / 5664x5664(LL)* *High Resolution Mode. 2880x2880(4K PHOTO) / 4000x4000(HLG PHOTO, Full-Res.) / 2144x2144(HLG PHOTO, 4K-Res.) (65:24) 6000x2208(L) (2:1) 6000x3000(L) |
Color Space | sRGB, AdobeRGB |
Video Recording Format | MOV: H.264/MPEG-4 AVC, H.265/HEVC (Audio format: LPCM (2ch 48kHz/16-bit)); MP4: H.264/MPEG-4 AVC, H.265/HEVC (Audio format: AAC (2ch)) |
Video Resolution | MP4 ([4K] 3840x2160); MP4 HEVC** ([4K] 3840x2160); AVCHD Progressive** (1920x1080) |
Continuous recordable time (Motion picture) | Approx. 150 min (rear monitor), 140 min (LVF) in [AVCHD/FHD/60p] *When using S-R24105 and SD Memory Card. |
6K & 4K PHOTO MODE | Yes |
Recording Media | SD Memory Card: Dual slot |
CONNECTIVITY | |
WiFi | IEEE 802.11b/g/n, 2412 MHz - 2462 MHz (1-11 ch), Wi-Fi / WPA / WPA2, Infrastructure mode |
Bluetooth | Bluetooth® v4.2 (Bluetooth Low Energy (BLE)) |
INTERFACE | |
USB | USB Type-C, Super Speed USB3.1 GEN1 |
HDMI | Yes, Micro |
Audio Video Output | Yes |
Remote input | φ2.5mm for remote |
External microphone input | Yes |
Headphone output | Yes |
High-res audio recording | Yes |
Microphone | Stereo, Wind-cut: OFF / Standard / High |
Speaker | Monaural |
LCD MONITOR | |
Size / Pixels | High resolution 1.84 million-dot: Free angle, 3.2-inch (8.0cm), 3:2 aspect |
VIEWFINDER | |
Size / Pixels | OLED Live View Finder, Approx. 2,360k dots.; 0.74x |
FOCUS | |
AF Mode | Auto Detection (Face, Eye, Body, Animal) / Tracking / 225-Area / Zone (Vertical/Horizontal) / Zone (Square) / Zone (Oval) / 1-Area+ / 1-Area / Pinpoint / Custom 1, 2, 3 (Full area touch is available) (Scalable AF frame size and flexible AF position) |
EXPOSURE CONTROL | |
Light Metering System | 1,728-zone multi-pattern sensing system |
Light Metering Mode | Multiple / Center Weighted / Spot / Highlight Weighted |
Exposure Mode | Program AE, Aperture Priority AE, Shutter Priority AE, Manual |
ISO Sensitivity | Auto / 50* / 100 / 200 / 400 / 800 / 1600 / 3200 / 6400 / 12800 / 25600 / 51200 / 102400* / 204800* (Changeable to 1/3 EV step) *Extended ISO |
Dual Native ISO | [Normal] Native ISO: 100, 640; Auto: Auto / 50* / 100-51200 / 102400* / 204800* *Extended ISO [V-Log] Native ISO: 640, 4000; Auto: Auto / 320* / 640-51200 *Extended ISO [HLG] Native ISO: 400, 2500 ; Auto: Auto / 400-51200 / 102400* / 204800* *Extended ISO [Cinelike D2 / Cinelike V2] Native ISO: 200, 1250 ; Auto: Auto / 100* / 200-51200 / 102400* / 204800* *Extended ISO |
Exposure Compensation | 1/3 EV step ±5EV (±3EV for motion picture) |
SHUTTER | |
Type | Focal-plane shutter |
Shutter Speed | Still image: Bulb (Max. 30 minutes), 1/8,000 - 60; Electronic front curtain shutter: Bulb (Max. 30 minutes), 1/2,000 - 60; Electronic shutter: Bulb (Max. 60 sec), 1/8,000 - 60; Motion picture: 1/16,000 - 1/25; Creative Video M mode / MF mode: 1/16,000 - 1/2 |
BURST SHOOTING | |
Burst Speed | [Mechanical Shutter] AFS/MF: H: 7 frames/sec, M: 5 frames/sec (with Live View), L: 2 frames/sec (with Live View) AFC: H: 5 frames/sec (with Live View), M: 5 frames/sec (with Live View), L: 2 frames/sec (with Live View) ; [Electronic shutter] AFS/MF: H: 9 frames/sec, M: 5 frames/sec (with Live View), L: 2 frames/sec (with Live View) |
Number of Recordable Images | RAW / RAW+JPEG: More than 24 images; JPEG: More than 999 images (When using a card with SD Speed Class with "UHS-II UHS Speed Class 3 (U3)" inserted into card slot 1.) * When recording is performed under the test conditions specified by Panasonic. |
BRACKET | |
AE Bracket | 3, 5, 7 images in 1/3, 2/3 or 1 EV step, max. ±3 EV, single/burst |
White Balance Bracket | 3 images in blue/amber axis or in magenta/green axis, color temperature setting |
Aperture Bracket | 3, 5 or all positions in 1 EV step |
Focus Bracket | 1 to 999 images, focus steps can be set in 10 levels |
FLASH | |
Flash Type | TTL External Flash (sold separately) |
Flash Mode | Auto*, Auto/Red-eye Reduction*, Forced On, Forced On/Red-eye Reduction, Slow Sync., Slow Sync./Red-eye Reduction, Forced Off* For iA, iA+ only. |
Flash Output Adjustment | 1/3EV step +/-3EV |
CREATIVE CONTROL | |
Photo Style | Standard / Vivid / Natural / Flat / Landscape / Portrait / Monochrome / L. Monochrome / L. Monochrome D / Cinelike D / Cinelike V / Like709 / Standard (HLG) / Monochrome (HLG) / Like2100 / M |
Still Image | - |
Movie Mode | Program AE/ Aperture-Priority / Sutter-Priority / Manual Exposure / Variable frame rate |
LANGUAGE | |
OSD language | Japanese, English, German, French, Italian, Spanish |
POWER | |
Battery | Li-ion battery (included) DMW-BLK22 (2200mah) |
Battery life (CIPA standard) | Approx. 440 images (rear monitor), 470 images (LVF), 1,500 images (Power Save LVF mode*) with S-R2060; *Under the test conditions specified by Panasonic based on CIPA standard. When the time to get in the sleep mode is set to 1 sec. |
PHYSICAL | |
Dimensions (W x H x D) | Approx. 132.6 x 97.1 x 81.9 mm / 5.22 x 3.82 x 3.22 inch (excluding protrusions) |
Weight | Approx. 714g / 1.58 lb (SD Memory Card x 1, Battery, Body); Approx. 630g / 1.39 lb (Body only) |
Software | LUMIX Tether; This software is used to control a Panasonic digital camera from a PC. It allows you to change various settings of the camera, perform remote recording, and save remotely recorded images to the PC. Check the site below to download and install the software; http://panasonic.jp/support/global/cs/soft/download/d_lumixtether.html (For Windows / Mac) |
