Miller Arrowx 7 Fluid Head
Miller
£5,072.40
(Inc. VAT)
£4,227.00
(Ex. VAT)
Write a Review
Miller
Miller Arrowx 7 Fluid Head
Miller ArrowX 5 Fluid Head (1074)
Following in the tradition and reputation of the world-renowned Arrow series, the all-new Miller 1074 ArrowX 5 Fluid Head, sets new dimensions in professional camera support, augmenting the power of expression of creative professionals.
Featuring a wide payload range, precision fluid drag and the Miller innovative 16 position CB Plus™ counterbalance system. The Arrowx 5 delivers the flexibility, speed of set up and accuracy of shot, professionals expect and demand.
2-21kg (4.4-46.2lbs) payload range and 7 0 selectable pan-tilt fluid drag positions make Arrowx 5 ideal for ENG and EFP. Thus enabling it to be used with a wide range of cameras, lenses and accessories and offering.
CB Plus™ is an innovative sequential counterbalance design, taking traditional counter balancing a step forward ahead of the rest, resulting in repeatable, accurate and rapid setup. CB Plus™ features eight larger counterbalance steps, allowing the user to get to their required counterbalance position quickly and efficiently. The CB Plus™ "one flick" switch conveniently located at the front of the head, adds a half step between each of the eight larger steps enabling counterbalance fine-tuning when required.
The new Arrowx 5 comes with the reliability and "THE RIGHT FEEL" that are the hallmarks of every Miller product.
| Payload Range | 2.0-21.0kg (4.4-46.2lbs) |
| Weight | 3.4kg (7.4lbs) |
| Counterbalance Positions | 16 selectable positions |
| Pan Tilt Drag | 7 selectable fluid drag positions + 0 |
| Pan Tilt Locks | Positive lock calliper brake system |
| Tilt Range | + 90°/ -75° |
| Pan Range | 360° |
| Camera Platform | Quick release camera plate (Euro) |
| Sliding Range | 120mm (4.7") |
| Mounting Base | Ø100mm (3.9") ball levelling with 3 x M5 holes for flat base mounting |
| Height Above Bowl | 162mm (6.4") |
| Illuminated Controls | Bubble level, pan-tilt drag controls |
| Pan Handle | Telescopic 390-590mm (15.4-23.2") |
| Temperature Range | -40° to +65°C (-40° to +149°F) |
- Compact, lightweight and versatile.
- 7 selectable of fluid pan and tilt drag
- 16 position CB PlusTM counterbalance system.
- Wide payload range 2-21kg (4.4-46.2lbs).
- Fluid drag system with smooth start and soft stop technology & balanced diagonal transitions.
- Controls "all in one location" design for fast, easy and practical use.
- Illuminated bubble level and pan-tilt drag controls.
- Precise floating pan-tilt calliper locks ensure bounce free on-off performance.
- Quick release, 120mm sliding camera platform with camera plate (euro).
- Removable ball level stud for flat base mounting (Sliders) with 3/8" screw hole.
- Mitchell base adaptable.
- Robust construction for rugged outdoor shooting conditions.
- Optional second pan handle mount.
- Side mounting points for viewfinders and accessories.
