Vaxis Atom A5 Wireless Monitor

Vaxis Atom A5 Wireless Monitor

£498.00 - £1,260.00 (Inc. VAT)
£415.00 - £1,050.00 (Ex. VAT)
SKU: VAXIS-ATOM-A5

Current Stock:

Availability: NOW IN STOCK!
Adding to cart… The item has been added

VAXIS ATOM A5 WIRELESS MONITOR

Highly Integration New Experience​
AllInOne Video Transmission System + Monitor Video Record + Playback Wireless Video Transmit + Receive

Superior Performance

5.5" Standard Pixel , Super Retina Screen

Accurate Sharpening. No fear of bright sunlight,clearly display picture details.

  • Peak Brightness: 1000Nits
  • Contrast Ratio: 1200:1
  • Sharp Display: 401 PPI
  • Real Test Data from Vaxis Lab

Video Transmission System & Monitor In One
Wireless Monitoring. Video transmission system and monitor unit as one.

150m Transmission Range
Extreme Distance. Remains stable for long distances,meets most usage scenarios.

Lower Latency Faster Follow Focus
80ms Delay. Almost insensitive time-lapse, easy to follow focus.

Dual NPF Battery Slots
Ultra-low Power Consumption. A single NPF- 550 battery (3500mAh) can last up to 4.5 hours of continuous use.

Multiple Ports
Dual HDMI Ports. Support HDMI loop out, it can be used as an on-camera monitor or as a receiver to loop out signal to broadcast monitor.

Break The Chain
5.5" Screen Adaptation. Redesigned CINE os for 5.5" monitor screen, new interactive way, increase your creative passion.

New Menu
Graphical operation menu, better visual effects.

Scope
Accurate picturey restore the most realistic colour and exposure.

3D-LUT
Customise 5 shortcuts up to 50 LUTs can be stored in the monitor.

Peaking
AFCA intelligent focus assist algorithm, sharp focusing.

Zoom
Multi-touch, two-finger zoom.

TX/RX in One
Both TX and RX. The transmit and receive states can be switched according to your existing Atom series products.

Record & Playback
Record & Playback in one. The recorded MPG-4 files are stored in the TF Card, you can instantly playback and review the footage on set. Preserved files can also be edited directly as proxy files.

Synchronous Recording
Timecode Sync. No need to manually record. When the camera starts recording, both the transmitter and receiver will start reording synchronously.

Follow Focus Kit
Mini Tripod & Handle, Wireless Lens Control, Quick Release Plate, Express install to form a follow focus kit

Compatible For All Atom Series Products

Specifications

  • Interface: DC IN, DC OUT, DC IN, DC OUT, 3.5mm Audio Jack, Type- -C, 3.5mm-lR IN
  • Input Voltage: NPF970/DC1 2V
  • Screen size: 5.5 Inch Touch
  • Screen resolution: 1920*1080 pixels
  • Screen Brightness: 1000cd/m
  • Contrast Ratio: 1200：1
  • Input Video Format: 1920*1080P 60/59.94/50/30/29.97/25/24/23.98 1920*1 080160/59.94/50 1280*720P 60/59.94/50
  • Output video format: 1920*1080P60/50/30/25/24 1920*1080160/50 1280*720P60/50
  • Audio format: 48KHz
  • Net Weight: 48g
  • Size: 151*92*30.5mm
  • DC Max Output Power: 8.5V/0.6A
  • Wireless Operating Frequency: 5.1G- -5.8G
  • Transmitting Frequency: 17dBm
  • Transmission Latency: 80ms, 120ms(under interference environments)
  • WReceiving Sensitivity: -80dBm
