Canon CN10X25 IAS S Lens
Canon Professional CamerasCall for pricing
Write a Review
Canon Professional Cameras
Canon CN10X25 IAS S Lens
Canon CN10X25 IAS S. Capture stunning 4K quality footage thanks to outstanding optical performance, operability and reliability. This versatile and cinematic 25mm-250mm 10x CINE-SERVO lens offers further reach up to 375mm in Full Frame mode (from the standard 250mm), with its 1.5x extender.
Cinematic look with 4K/8K Optical Quality
Designed to produce sharp images from centre to outer edges, even when paired with 8K cameras. The lens also produces the beautiful warm colour tones synonymous with Canon’s cinema lens family.
Wide Focal Length Coverage
The 10x zoom lens can handle a wide range of shooting situations, from 25mm wide angle, to 250mm telephoto, in a single lens. You can push this range to 375mm with the built-in 1.5x Optical Extender.
Supports Super 35mm and Full Frame cameras
The compact and lightweight lens covers a range from 25mm-250mm. The built-in extender increases the image size when used with 35mm Full Frame sensor cameras.
Flexible Design with Interchangeable Mounts, and detachable Drive Unit
You can add or remove the ergonomic drive unit to give greater flexibility and versatility for your production requirements.
The lens mount can also be interchanged between EF & PL mount* providing even greater value and flexibility.
*additional cost via Canon Authorised Services
Multiple Data Communication Functions and Support
The lens is compliant with a wide-range of communication standards thanks to the versatile lens-to-camera communication function which supports EF mount, PL mount, including Cooke /i Technology.
Canon CN10X25 IAS S also supports a 12-pin serial communication for broadcast standards, as well as a 20-pin connector which outputs accurate lens positional data for various virtual systems.
- 4K/8K Resolutions Supported
- High Power 10x Zoom (25mm-250mm)
- Built-in 1.5x Optical Extender
- Super 35mm and 35mm Full Frame Support
- Detachable Drive Unit
- 12-Pin Serial Communication supporting EF and PL mount lenses
- Interchangeable Lens Mounts (EF & PL)
Specification
Mount
PL Mount* : CN10x25 IAS S/P1
EF Mount* : CN10x25 IAS S/E1
Zoom ratio
10x
Built-in optical extender
1.5x
Focal length
25-250mm
(with Extender)
37.5-375mm
Maximum diameter ratio (T-number)
T2.95 at 25 - 187 mm / T3.95 at 250 mm
(with Extender)
T4.4 at 37.5 - 281 mm / T5.9 at 375 mm
Number of iris blades
11 Blades
Angle of view
Aspect Ratio 1.78: 1 (Sensor Size 24.6 x 13.8mm)
52.4⁰ x 30.9⁰ at 25 mm
5.6⁰ x 3.2⁰ at 250 mm
(with Extender)
36.3⁰ x 20.9⁰ at 37.5 mm
3.8⁰ x 2.1⁰ at 375 mm
Aspect Ratio 1.9:1 (Sensor Size 26.2 x 13.8mm)
55.3⁰ x 30.9⁰ at 25 mm
6.0⁰ x 3.2⁰ at 250 mm
(with Extender)
38.5⁰ x 20.9⁰ at 37.5 mm
4.0⁰ x 2.1⁰ at 375 mm
Aspect Ratio 1.9:1 (Sensor Size 38.1 x 20.1mm)
Full Frame (with Extender only)
53.9⁰ x 30.0⁰ at 37.5 mm
5.8⁰ x 3.1⁰ at 375 mm
Aspect Ratio 1.5:1 (Sensor Size 36 x 24mm)
Full Frame (with Extender only)
51.3⁰ x 35.5⁰ at 37.5mm
5.5⁰ x 3.7⁰ at 375 mm
Minimum shooting distance
1.2 m / 4.0'
Shooting range at closest approach
Aspect Ratio 1.78: 1 (Sensor Size 24.6 x 13.8mm)
86.5 x 48.5 cm at 25 mm
8.7 x 4.9 cm at 250 mm
(with extender)
57.7 x 32.3 cm at 37.5 mm
5.8 x 3.3 cm at 375 mm
Aspect Ratio 1.9:1 (Sensor Size 26.2 x 13.8mm)
92.1 x 48.5 cm at 25 mm
9.3 x 4.9 cm at 250 mm
(with extender)
61.4 x 32.3 cm at 37.5 mm
6.2 x 3.3 cm at 375 mm
Aspect Ratio 1.9:1 (Sensor Size 38.1 x 20.1mm)
Full Frame (with Extender only)
89.3 x 47.1 cm at 37.5 mm
9.0 x 4.8 cm at 375 mm
Aspect Ratio 1.5:1 (Sensor Size 36 x 24mm)
Full Frame (with Extender only)
84.4 x 56.2 cm at 37.5 mm
8.5 x 5.7 cm at 375 mm
Front diameter
Ф114 mm
Outer dimensions（w x h x d）
EF Mount
Approx. 7.6 x 5.2 x 11.1 in. /
Approx. 186.7 x 131.7 x 282.1 mm
PL Mount
Approx. 7.6 x 5.2 x 10.8 in. /
Approx. 186.7 x 131.7 x 274.1 mm
Weight
Approx. 6.7 lbs. / 3.06 kg
