About the Canon CN-E 30-300mm T2.95-3.7 L SP PL Mount Cinema Zoom Lens

Smaller and lighter the Canon CN-E 30-300mm T2.95-3.7 L SP PL Mount Cinema Zoom Lens  has superb optical performance. Exceeding the excellent resolution of prime models at all zoom levels this lens will minimize and correct distortion.  From the centre of the screen to the periphery, image rendering combines softness with high contrast.

The Canon CN-E 30-300mm T2.95-3.7 PL Mount Cinema Lens is designed expressly for digital cinematography with cameras that have an APS-C or Super 35-equivalent sensor and a PL mount, including Canon's EOS C300 PL. Featuring advanced optical technology designed by Canon, the lens is suitable for any capturing any size HD image up to and including 4K resolution.

With a focal length range of 30-300mm, the 10x cinema zoom lens is designed to cover the longer end of the focal lengths typically required by cinematic productions, and its maximum telephoto length of 300mm puts it among the best in its class. (The other zoom lens in the line, the CN-E 14.5-60mm T2.6 L SP, covers the wider end). Maximum aperture is a relatively fast T2.95 throughout much of its range, and the 11-blade iris enables a smooth bokeh for out-of-focus areas of the frame.

The lens was designed with working professionals in mind, with easy-to-read focus, zoom, and iris markings engraved into angled surfaces on both sides of the lens, so you can read the setting from either side of a camera or from behind. Depending on the production's needs, focus markings can be switched from standard to metric. The lens facilitates manual operation that's subtle, smooth, precise, and repeatable. Control rings are designed to provide and maintain the proper amount of resistance so you can operate with a consistent torque. The focus rotation angle is about 300°; while for zoom, it is approximately 160°.

The CN-E 30-300mm T2.95-3.7 L SP lens complements the other lens in the line in more ways than just focal length range: Their shared 136mm front diameter, gear positions, and rotation angle make them almost "hot-swappable" when they're used with a shared matte box or follow focus.

  • Covers APS-C & Super 35 Sensor Sizes
  • Suitable for 4K Image Capture
  • 11-Blade Iris for Smooth Bokeh
  • Geared Inner Focusing Reduces Breathing
  • Easy-to-Read Engraved Markings
  • 160° Rotation for Zoom
  • 300° Rotation for Focus
  • Weighs 12.8 lb



Internal Focus Design
The internal geared focus design of the lens minimizes focus-induced changes, known as "breathing"

Cinematic Blurring
An 11-blade aperture diaphragm results in soft, cinematic blurring of out-of-focus areas.

Special Glass & Construction
Designed to counteract barrel expansion and contraction, the special glass and the construction of the lens suppress temperature-induced marking discrepancies and flange-back changes

Broad Focal Length Range
The 30-300mm focal length range of the lens covers a great portion of the range most commonly used in cinema shooting

Large Aspherical Lenses
Fluorite and aspherical lens elements reduce distortion and give high optical performance

Anti-Reflective Coating
The anti-reflective coating of the lens helps reduce ghosting or flaring

Switchable Unit for Focus Marking
The outer piece on marked focus rings can be switched from metric to non-metric labeling.

Marked on Both Sides
Markings are visible from either side of the lens

Better Marking Visibility
Focus, zoom, and iris markings are printed on angled surfaces, making them easier to read from behind the camera

Unified Front Lens Diameter, Gear Position
A single front lens diameter and uniform gear positions across the line of lenses eliminate the need to move or adjust accessories when switching between lenses

Flange-Back Adjustment Mechanism
A covered flange-back mechanism is included for more accurate back-focus

Supports Standard Accessories
The lens can be used with standard accessories such as follow focus gears, marking disks, and matte boxes
Control rings offer the right amount of resistance and consistent operating torque

Light & Compact
Smaller and lighter than similar movie lenses of the same range, making them more comfortable to work with, hour after hour.

Focal Length 30 - 300mm
Lens Mount ARRI PL
Format Super 35/APS-C
Image Circle Not specified by manufacturer
Maximum T-Stop T2.95 - 3.7
Minimum T-Stop Not specified by manufacturer
Diagonal Angle of View Super 35: 51.6 - 5.4°
Minimum Focus Distance from Image Plane 5'; / 1.5 m
Elements/Groups Not specified by manufacturer
Iris Blades 11
Front Diameter 136 mm
Filter Thread Not specified by manufacturer
Focus Scales Not specified by manufacturer
Zoom Ratio 10x
Electronic Communication Not specified by manufacturer
Tripod Mounting Thread Not specified by manufacturer
Dimensions (W x H) 5.67 x 6.58" / 144.0 x 167.1 mm
Length 13.47" / 342.1 mm
Weight 12.79 lbs / 5.8 kgv
Packaging Info
Package Weight 19.2 lb
Box Dimensions (LxWxH) 23.4 x 14.3 x 14.1"
